PARTS LIST - Page 2       Page 1

 8. Swing shaft
 9. String
10. Brass shaft (escapement shaft)
11. Brass shaft (middle shaft)
12. Brass shaft (bottom shaft)
13. Nylon washer (8)
16. Steel pin (1)

23. Steel pin (4)
28. "O" Ring
29. Pulley
32. Washer (2)
34. Brass shaft (minute hand)
36. Bushing
38. Dial pin (3)

41. Bushing
42. Washer
44. Washer
46. Steel pin (4)
54. Pull cord
55. Heat shrink tube (2)
